Sonoff TH16


WiFi Smart Switch, temperature and humidity sensor

Tax included


Get emailed when we have stock again

Create the alert to receive an email once we have stock back.


Sonoff TH16 Smart WiFi Switch, temperature and humidity sensor

Wireless temperature and humidity monitoring switch which can remotely monitor and set the temperature and humidity range to turn on / off the connected appliances via the eWeLink iOS / Android APP.

As the name indicates, the Sonoff TH temperature and humidity monitoring device supports two power supply specifications of maximum current: 15A.

Sonoff TH16 WiFi supports preselection of temperature or humidity range.

When the temperature or humidity of the home environment is within the range, it will automatically turn on or off the connected devices. Sonoff TH16 supports four types of temperature monitoring and humidity monitoring sensors, mentioned below: Si7021, AM2301, DS18B20, AL560, MS01.

The sensor must be connected to the smart switch before power on.

It is not recommended to plug or unplug the sensor after power on. DS18B20 is waterproof, which can only measure temperature.

Other sensors can measure both temperature and humidity. With the eWeLink app, users can create simple conditional statements (Smart Scenes) to activate / deactivate other smart devices. This means that users can use Sonoff TH16 with Si7021 , AM2301 , DS18B20 , AL560 , MS01 sensor to detect the temperature / humidity, then set the specified temperature.

This device works perfectly with electric fan, air conditioner, humidifier, smart aquarium, irrigation system, etc.

Supported temperature and humidity sensors: SI7021 - AM2301 - DS18B20 - AL560 - MS01

Features :

Support tracking device status

Support remote power on / off of connected equipment

Supports temperature and humidity preselection to be turned on / off Supports 8 enabled / single / repeating countdown tasks

Support for real-time temperature and humidity control

Support setting a smart scene to turn on / off other smart devices

Works with Amazon Echo, Echo Dot, Amazon Tap, Google Home, Google Home Mini, Google Nest Works with IFTTT

Technical features

Template TH16
Diet 100-240V AC 50 / 60Hz
Maximum load 15A 3500W
Wifi IEEE 802.11 b / g / n 2.4GHz
Material PC V0
Dimensions 114x51x32 mm
Operating temperature 0ºC-40ºC (32 ° F-104 ° F)
Humidity 5% -90% RH, non-condensing

Product Details

Data sheet

Mobile application
Communication Protocol
Number of Channels
