Riferimento: beca-bac-005alw
Marca: Beca
Termostato WiFi Beca BAC-005ALW Fan Coil
Termostato Smart WiFi Controllo Condizionatori a 2 Tubi
Specially designed for the control of your air conditioners, you can control the system based on the temperature or weekly programming.
Support forward synchronization with local weather.
The intuitive 4.8-inch color LCD display offers a clear and simple view of all available information. A solution with an elegant, modern and discreet design. The thickness from the wall is only 1.4 cm.
The thermostat is programmable through the SmartLife app or through the comfortable touch keys.
Compatible with Amazon Alexa, Google Home and IFTTT, this thermostat will allow you to constantly monitor your system, maintaining the most comfortable temperature while saving energy.
Features:
WiFi temperature control , for Android and for iOS WIFI control.
Remote control via mobile application or computer (WIFI), manage the temperature of your home from anywhere in the world.
Programmability: 5 + 2 programmable periods maximize comfort and economy. programs guarantee a comfortable temperature, more options, more flexible; Support device sharing.
Accurate temperature: 1 ° C Accuracy keeps the temperature within the set level;
Data memory when the power is off; ℃ or ℉ can be customized; No limits to add rooms and support Smart Scenes.
System operation diagram and wiring diagram (4 pipes):
Four pipes: can flexibly realize simultaneous cooling and heating, without loss of mixing of cold and heat; the flow and return pipes for cooling and heating are set separately and there are two independent systems with cold and hot return water.
The principle of operation of four pipes: cold and hot coils in all terminal equipment work independently, and chilled water and hot water are sent to each terminal equipment independently at the same time.
Technical features |
|
---|---|
Sensor | NTC |
Precision | ± 1 ℃ |
Diet | 95-240 Vac / 50-60 hz |
Temperature range | 5-35 ℃ |
Fan Relay Amplifier Resistance: 5A | Inductive: 3A |
Resistance of valve relay amplifiers: 5A | Inductive: 3A |
Current Consumption | <1.5W |
Installation | 86X86mmx13.3 or 60mm European round box |
Timing error | <1% |
Material | PC + ABS |
Operation diagram | Summer - Winter Fancoil + Radiators |
Product Class | IP20 |
Wire terminals | 2 x 1.5 mm² or 1 x 2.5 mm² |
